Dial Size
- 800B: 1-1/2”, 2”, 2-1/2”, 4”
- 800LFB: 2”, 2-1/2”, 3-1/2”
Wetted Parts
- Bronze Tube, Brass Socket Lead-Free (PBF)
- Meets NSF/ANSI Standards 372 and 61
Fill
- Glycerine
- Other fills available See Optional Features Section
Connection
- 1-1/2” Dial Size: Lower Male or Center Back Male, 1/8” NPT
- 2”, 2-1/2” Dial Size: Lower Male or Center Back Male, 1/8” or 1/4” NPT
- 4” Dial Size: Lower Male or Center Back Male, 1/4” NPT
- Lower Male or Center Back Male 1/8” or 1/4” NPT
Case
- Drawn Steel, Black Finished, Stem-Mounted Flangeless
- 2”, 2-1/2” Dial Size: ABS Plastic, Stem-Mounted Flangeless
- 3-1/2” Dial Size: Nylon, Stem-Mounted Flangeless
Ring
- Crimped Aluminum, Black Finished
Window
- Acrylic
- Styrene-Acrylonitrile
Dial Face
- Aluminum, White Background with Black Graduations and Markings
Accuracy
- ± 1.6 % Full Scale
- 2”, 2-1/2” Dial Size: ± 1.6 % Full Scale
- 3-1/2” Dial Size: ± 1.0 % Full Scale, ASME B40.100 Grade 1A
Maximum Temperature
- 180° F (82° C)
- 150° F (65° C)
Approximate Shipping Weight
- 1-1/2” Dial Size: 0.2 lbs [0.09 kg]
- 2” Dial Size: 0.3 lbs [0.14 kg], 0.4 lbs [0.18 kg]
- 2-1/2” Dial Size: 0.3 lbs [0.14 kg], 0.5 lbs [0.23 kg]
- 3-1/2” Dial Size: 1.0 lbs [0.45 kg]
- 4” Dial Size: 0.6 lbs [0.27 kg]
