Images are representations only.

NGC8209

Series: NGC8209 Natural Gas Chromatograph Brand: ABB Group

ABB Natural Gas Chromatograph

Price
$402.00 CAD
Stock
50+ In Stock
Request Information

Specifications

Brand

Media

  • Nitrogen, Methane, Carbon Dioxide, Ethane, Propane, Isobutane, Butane, NeoPentane, IsoPentane, Pentane, Hexanes, Heptane, Octane, Nonanes+

Material of Construction

  • Aluminum Alloy (with White Polyester Powder Coating)

Environmental Protection

  • ATEX Type 4X (IP66 Equivalent)
  • CSA Type 4X
  • IECEx IP56

Analysis Time

  • Approximately 360 seconds, cycles may be scheduled by user

Repeatability

  • ± 0.50 BTU @ 1,000 BTU (± 0.025 %) over Temperature Range
  • ± 0.25 BTU @ 1,000 BTU (± 0.0125 %) @ ambient

Storage Temperature

  • -22° to 140° F (-30° to 60° C)

Temperature Range

  • Cold Weather Enclosure: -40° to 130° F (-40° to 55° C)
  • Normal: 0° to 130° F (-18° to 55° C)

Humidity

  • 95 % Relative Humidity Non-Condensing

Power Consumption

  • Start up: 90 W at 15 Vdc, less than 6 A @ 0° F (-18° C)
  • Nominal: 14 W at 15 Vdc, 1300 mA @ 0° F (-18° F)

Certifications & Approvals

  • INMETRO Exd 11B + H₂ T6, Class 1 Zone 1
  • EMC - EMI/RFI: EN 55022, EN 61000-6-1, EN 61000-4-2, 4-3, 4-4, 4-6, 4-8, CISPR 22-2004
  • CE: ATEX II 2G: Ex d, IIB+H₂ T6, Class I, Zone 1
  • NEC & CEC Class I, Div. 1, Groups B, C and D, T6: CFR 47, Part 15
  • IECEx Exd IIB + H₂ T6, Class I, Zone 1

Miscellaneous Type Approvals

  • China Weight & Measures
  • BRML (Romania)
  • NMI (Netherlands)
  • Industry Canada

Communication

  • Optional USB Hub (Host and Client) and Ethernet Ports
  • One USB MMI (RS-232 or USB)
  • Two Serial Digital Ports, Software selectable for RS-232, RS-485, or RS-422

Protocols

  • Modbus ASCII or RTU (Modicon, WordSwap, or Danalyzer)
  • Modbus / TCP Client
  • Modbus / TCP Server
  • Totalflow / TCP
  • Totalflow Remote / Local MMI

Dimensions

  • 17.1 cm x 40.6 cm x 22.9 cm
  • 6.75” diameter x 16” long x 9.00” tall

Weight

  • Approximately 56 lb (25.4 kg)
  • Shipping: Approximately 94 lb (52 kg)

Documentation

Brochure

Catalog

Certificate

Manual
